Hebi Coal Chemical Machinery Co., Ltd. is a well-known domestic enterprise specializing in the production of feeders. Its vibrating feeders are well-known in China. Its production of various belt feeders is also sold well at home and abroad. The reducer on the belt feeder , is the key part of the equipment, if the installation is not good, it will cause various quality and after-sales problems, so what problems should be paid attention to when installing the deceleration? The following points should be noted:
1. The installation site of the reducer should be separated from heat radiation. If it is installed in a very hot or cold place, there must be measures for cooling and cooling and heating lubricating oil to ensure normal startup.
2. The concrete foundation or metal bottom plate on which the reducer is installed must have sufficient rigidity; the anchor bolts are embedded to a sufficient depth, and when using gaskets for leveling, the thickness of the gaskets should not be less than 1mm; to ensure that the load is stable and does not deform.
3. To find the level, the motor and the reducer should be on the same horizontal line. The higher the alignment accuracy, the better. The compensation ability of the coupling alignment error and the size of the tolerance should be considered. Generally, the axis angle error should not Greater than 1″, the translation error is less than 0.1mm
4. The anti-rust agent and anti-corrosion agent on the shaft extension must be cleaned before installing the coupling, sprocket and other parts on the shaft extension. To remove rust inhibitors and preservatives, do not use tools such as sandpaper, files, and scrapers that can easily damage the mating surface of the shaft. When installing couplings, sprockets, etc., do not hit with a heavy hammer, but use the method of thermal expansion and cold contraction.
5. Read the manual carefully and check the parameters on the reducer and motor to achieve a more scientific and reasonable performance configuration.
6. Install the feeder online monitoring system. The feeder online monitoring system launched by Hebi Coal Chemical Machinery Co., Ltd. can effectively monitor the operation status of each part of the feeder online. Once the main components such as the reducer motor are abnormal, it will alarm in real time to remind the troubleshooting.
Pay attention to the installation of the above reducer, which will reduce the quality hidden dangers in the installation of the reducer, and will surely make your feeder run safely. Hebi Coal Chemicals is a feeder manufacturing expert.
