The construction of coal loading stations plays an important role in improving transportation efficiency, alleviating the tension in transportation capacity, and accelerating the process of regional economic construction. WHG type vortex activated vibrating feeder, the key product of coal loading station, is an important equipment to ensure the smooth loading of coal.
The equipment has the characteristics of energy saving, high production efficiency, safety and reliability, small investment, wide application range, easy maintenance and strong adaptability.
Working principle and characteristics of WHG vortex activation vibrating feeder:
By starting the vibrating motor installed on both sides of the circular vibrating tank, the exciting force generated by the eccentric block of the motor is transmitted to the trough of the feeder, causing the trough to vibrate. Since the vibrating motor is installed at a certain angle, the exciting force generated by the motor Make the material in the tank body vortex, and its effect reaches 3-5 meters above the warehouse mouth. The material is activated more quickly and the feeding is faster.
WHG type vortex activation vibrating feeder features:
(1) The machine organically combines the feeding function and the function of activating the material to ensure that the material falls smoothly and effectively solves the problem of silo gambling.
(2) The two vibrating motors installed on the feeder have a certain angle. The exciting force generated by the motor makes the material in the tank body vortex, so that the material in the upper part of the tank body is activated more quickly and the material is discharged faster.
(3) The material is directly centered and dropped to the middle of the conveyor belt through the feeder, which prevents the problem of deviation caused by the side impact when the belt conveys the material.
(4) The performance of the feeder is reliable, the maintenance cost is low, the electric energy is saved, and the operation cost is low.
(5) The life cycle management system of the equipment can monitor the operation, loading and service life of each component in real time, and has the functions of automatic alarm and shutdown in case of emergency.
